TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
300
5.12 Send First Operations Record ( 3 5 12 )
Message Number
Definitions
00 87T Trip
01 87H Trip
02 51P-1 Trip
03 51N-1 Trip
04 50P-1 Trip
05 50N-1 Trip
06 150P-1 Trip
07 150N-1 Trip
08 46-1 Trip
09 51P-2 Trip
10 51G-2 Trip
11 50P-2 Trip
12 50G-2 Trip
13 150P-2 Trip
14 150G-2 Trip
15 46-2 Trip
16 ECI-1
17 ECI-2
18 Thru Flt
19 Harm Rest
31 Fault Clear Failed
32 Fault Cleared
33 Harmonic Restraint
34 Manual Trip
35 Manual Trip Failed
40 87T Enabled
41 87H Enabled
42 51P-1 Enabled
43 51P-2 Enabled
44 51N-1 Enabled
45 51G-2 Enabled
46 50P-1 Enabled
47 50P-2 Enabled
48 50N-1 Enabled
49 50G-2 Enabled
50 150P-1 Enabled
51 150P-2 Enabled
52 150N-1 Enabled
53 150G-2 Enabled
54 46-1 Enabled
55 46-2 Enabled
56 ALT1 Input Closed
57 ALT2 Input Closed
58 Event Cap1 Init
59 Event Cap2 Init
60 Wave Cap. Init
61 Trip Input Closed
62 SPR Input Closed
63 TCM Input Closed
64 Primary Set Active
65 Alt1 Set Active
66 Alt2 Set Active
70 Thru Flt Cntr Alm
71 Thru Flt kASum Alm
72 Thru Flt Cycle Alm
