TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
314
11 Receive Edit Buffer "N" Commands (3 11 n)
N
Definition
0 Reserved for repeat 3 11 n
1 Programmable Input Select and Index Tables
2 Programmable Input Negated AND Table
3 Programmable Input AND/OR Table
4 Programmable Input User Defined Input Names
5 Programmable Output Select Table
6 Programmable Output AND/OR Table
7 Programmable Output User Defined Output Names
8 Primary Relay Settings
9 Alternate 1 Relay Settings
10 Alternate 2 Relay Settings
11 Configuration Settings
12 Counter Settings
13 Alarm Settings
14 Real Time Clock
15 Output Delays
11.1 Receive Programmable Input Select and Index ( 3 11 1 )
Bit = 0, Physical Input is selected.
Bit = 1, Physical Input is not selected.
Low byte consists of bits 0 through 7.
High byte consists of bits 8 through 15.
Index byte is the offset into the TPU's logical input structure.
Offset
Definitions
00 87T Restrained Differential Trip
01 87H High Set Inst Differential Trip
02 51P-1 Wdg1 Phase Time OC Trip
03 51P-2 Wdg2 Phase Time OC Trip
04 51N-1 Wdg1 Neutral Time OC Trip
05 51G-2 Wdg2 Ground Time OC Trip
06 50P-1 1st Wdg1 Phase Inst OC Trip
07 50P-2 1st Wdg2 Phase Inst OC Trip
08 50N-1 1st Wdg1 Neutral Inst OC Trip
09 50G-2 1st Wdg2 Ground Inst OC Trip
10 150P-1 2nd Wdg1 Phase Inst OC Trip
11 150P-2 2nd Wdg2 Phase Inst OC Trip
12 150N-1 2nd Wdg1 Neutral Inst OC Trip
13 150G-2 2nd Wdg2 Ground Inst OC Trip
14 46-1 Wdg1 Neg Seq Time OC Trip
15 46-2 Wdg2 Neg Seq Time OC Trip
16 ALT1 Enables Alt 1 Settings
17 ALT2 Enables Alt 2 Settings
18 ECI1 Event-1 Capture Initiated
19 ECI2 Event-2 Capture Initiated
20 WCI Waveform Capture Initiated
21 Trip Initiates Diff Trip Output
22 SPR Sudden Pressure Input
23 TCM Trip Coil Monitoring
24 ULI1 User Logical Input 1
25 ULI2 User Logical Input 2
26 ULI3 User Logical Input 3
27 ULI4 User Logical Input 4
28 ULI5 User Logical Input 5
