TPU2000/2000R Modbus/Modbus Plus Automation Guide
315
29 ULI6 User Logical Input 6
30 ULI7 User Logical Input 7
31 ULI8 User Logical Input 8
32 ULI9 User Logical Input 9
33 CRI Resets OC Trip and all Recloser Counters
Msg byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
2/2 Spare
2/3 Command + Subcommand = 0xb1
3/1 INPUT1 high byte
3/2 INPUT1 low byte
3/3 INPUT1 index byte
4/1 INPUT2 high byte
4/2 INPUT2 low byte
4/3 INPUT2 index byte
5/1 INPUT3 high byte
5/2 INPUT3 low byte
5/3 INPUT3 index byte
6/1 INPUT4 high byte
6/2 INPUT4 low byte Bit Physical Input
6/3 INPUT4 index byte --- --------------
7/1 INPUT5 high byte 0 IN6
7/2 INPUT5 low byte 1 IN7
7/3 INPUT5 index byte 2 IN8
8/1 INPUT6 high byte 3 IN2
8/2 INPUT6 low byte 4 IN9
8/3 INPUT6 index byte 5 IN3
9/1 INPUT7 high byte 6 IN4
9/2 INPUT7 low byte 7 IN5
9/3 INPUT7 index byte 8 IN1
10/1 INPUT8 high byte 9 Reserved
10/2 INPUT8 low byte 10 Reserved
10/3 INPUT8 index byte 11 Reserved
11/1 INPUT9 high byte 12 Reserved
11/2 INPUT9 low byte 13 Reserved
11/3 INPUT9 index byte 14 Reserved
12/1 INPUT10 high byte 15 Reserved
12/2 INPUT10 low byte
12/3 INPUT10 index byte
13/1 INPUT11 high byte
13/2 INPUT11 low byte
13/3 INPUT11 index byte
14/1 INPUT12 high byte
14/2 INPUT12 low byte
14/3 INPUT12 index byte
15/1 INPUT13 high byte
15/2 INPUT13 low byte
15/3 INPUT13 index byte
16/1 INPUT14 high byte
16/2 INPUT14 low byte
16/3 INPUT14 index byte
17/1 INPUT15 high byte
17/2 INPUT15 low byte
17/3 INPUT15 index byte
18/1 INPUT16 high byte
