TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
318
19/3 INPUT26 high byte
20/1 INPUT26 low byte
20/2 INPUT27 high byte
20/3 INPUT27 low byte
21/1 INPUT28 high byte
21/2 INPUT28 low byte
21/3 INPUT29 high byte
22/1 INPUT29 low byte
22/2 INPUT30 high byte
22/3 INPUT30 low byte
23/1 INPUT31 high byte
23/2 INPUT31 low byte
23/3 INPUT32 high byte
24/1 INPUT32 low byte
24/2 Checksum high byte
24/3 Checksum low byte
11.3 Receive Programmable Input AND/OR Select ( 3 11 3 )
Bit = 0, Selected inputs are ORed together.
Bit = 1, Selected inputs are ANDed together.
Msg byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
2/2 spare
2/3 Command + Subcommand = 0xb3
3/1 Programmable input AND/OR selection bits 24-31
3/2 Programmable input AND/OR selection bits 16-23
3/3 Programmable input AND/OR selection bits 8-15
4/1 Programmable input AND/OR selection bits 0-7
4/2 Checksum high byte
4/3 Checksum low byte
Bit Logical Input
--- ------------
0 INPUT1
1 INPUT2
.
.
.
27 INPUT28
28 INPUT29
29 INPUT30
30 INPUT31
31 INPUT32
11.4 Receive Programmable Input User Defined Strings ( 3 11 4 )
User definable 8 char input strings. Byte 9 is an implied NULL
Msg byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
2/2 spare
