TPU2000/2000R Modbus/Modbus Plus Automation Guide
319
2/3 Command + Subcommand = 0xb4
3/1-5/2 IN1 Character String 8 bytes
5/3-8/1 IN2 Character String 8 bytes
8/2-10/3 IN3 Character String 8 bytes
11/1-13/2 IN4 Character String 8 bytes
13/3-16/1 IN5 Character String 8 bytes
16/2-18/3 IN6 Character String 8 bytes
19/1-21/2 IN7 Character String 8 bytes
21/3-24/1 IN8 Character String 8 bytes
24/2-26/3 IN9 Character String 8 bytes
27/1-29/2 spare Character String 8 bytes
29/3-32/1 spare Character String 8 bytes
32/2-34/3 spare Character String 8 bytes
35/1-37/2 spare Character String 8 bytes
37/3-38/1 spares
38/2 Checksum high byte
38/3 Checksum low byte
11.5 Receive Programmable Output Select ( 3 11 5 )
Programmable Output data transferred from PC to TPU2000.
Bit = 0, Physical Output is selected.
Bit = 1, Physical Output is not selected.
Least significant low byte consists of bits 0 through 7.
Least significant high byte consists of bits 8 through 15.
Most significant low byte consists of bits 16 through 23.
Most significant high byte consists of bits 24 through 31.
Msg byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
2/2 spare
2/3 Command + Subcommand = 0xb5
3/1 Contact OUT5 most significant high byte
3/2 Contact OUT5 most significant low byte
3/3 Contact OUT5 least significant high byte
4/1 Contact OUT5 least significant low byte
4/2 Contact OUT7 most significant high byte
4/3 Contact OUT7 most significant low byte
5/1 Contact OUT7 least significant high byte
5/2 Contact OUT7 least significant low byte
5/3 Contact OUT4 most significant high byte
6/1 Contact OUT4 most significant low byte
6/2 Contact OUT4 least significant high byte
6/3 Contact OUT4 least significant low byte
7/1 Contact OUT6 most significant high byte
7/2 Contact OUT6 most significant low byte
7/3 Contact OUT6 least significant high byte
8/1 Contact OUT6 least significant low byte
8/2 Contact OUT3 most significant high byte
8/3 Contact OUT3 most significant low byte
9/1 Contact OUT3 least significant high byte
9/2 Contact OUT3 least significant low byte
9/3 Contact OUT2 most significant high byte
10/1 Contact OUT2 most significant low byte
10/2 Contact OUT2 least significant high byte
