TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
328
2/2 spare
2/3 Command + Subcommand = 0xbc
3/1 Through Faults Counter high byte (0-9999)
3/2 Through Faults Counter low byte
3/3 Thr Fault Sum kAmp A Counter high byte (0-9999)
4/1 Thr Fault Sum kAmp A Counter low byte
4/2 Through Fault Sum Cyc Counter high byte (0-99990)
4/3 Through Fault Sum Cyc Counter low byte
5/1 Overcurrent Trips Counter high byte (0-9999)
5/2 Overcurrent Trips Counter low byte
5/3 Differential Trips Counter high byte (0-9999)
6/1 Differential Trips Counter low byte
6/2 Thr Fault Sum kAmp B Counter high byte (0-9999)
6/3 Thr Fault Sum kAmp B Counter low byte
7/1 Thr Fault Sum kAmp C Counter high byte (0-9999)
7/2 Thr Fault Sum kAmp C Counter low byte
7/3 Spare
8/1 Spare
8/2 Checksum high byte
8/3 Checksum low byte
11.13 Receive Alarm Settings ( 3 11 13 )
Low byte consists of bits 0 through 7.
High byte consists of bits 8 through 15.
Msg byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
2/2 spare
2/3 Command + Subcommand = 0xbd
3/1 Through Faults Alarm Threshold high byte (0-9999)
3/2 Through Faults Alarm Threshold low byte
3/2 Through Fault Sum kAmp Alarm Thres high (0-9999)
4/1 Through Fault Sum kAmp Alarm Threshold low byte
4/2 Through Fault Sum Cyc Alarm high (0-99990, /10)
4/3 Through Fault Sum Cyc Alarm Threshold low byte
5/1 Overcurrent Trips Alarm high byte (0-9999)
5/2 Overcurrent Trips Alarm low byte
5/3 Differential Trips Alarm high byte (0-9999)
6/1 Differential Trips Alarm low byte
6/2 Phase Demand Alarm high byte (1-9999)
6/3 Phase Demand Alarm low byte
7/1 Neutral Demand Alarm high byte (1-9999)
7/2 Neutral Demand Alarm low byte
7/3 Load Alarm high byte (1-9999)
8/1 Load Alarm low byte
8/2 Phase Demand Alarm high byte (1-9999,10000=Disables)
8/3 Phase Demand Alarm low byte
9/1 Low PF Alarm high byte(0.5-1.0 *100, 101=Disables)
9/2 Low PF Alarm low byte
9/3 High PF Alarm high byte(0.5-1.0 *100, 101=Disables)
10/1 High Pf Alarm low byte
10/2 Positive kVAR Alarm high byte (10-99990 / 10,10000=Disable)
10/3 Positive kVAR Alarm low byte
11/1 Negative kVAR Alarm high byte (10-99990 /10,10000=Disable)
11/2 Negative kVAR Alarm high byte
