TPU2000/2000R Modbus/Modbus Plus Automation Guide
329
11/3 Pos Watt Alarm 1 high byte (1-9999, 10000=Disable)
12/1 Pos Watt Alarm 1 low byte
12/2 Pos Watt Alarm 2 high byte (1-9999, 10000=Disable)
12/3 Pos Watt Alarm 2 low byte
13/1 Spare
13/2 Spare
13/3 Spare
14/1 Spare
14/2 Spare
14/3 Spare
15/1 Spare
15/2 Spare
15/3 Spare
16/1 Spare
16/2 Spare
16/3 Spare
17/1 Spare
17/2 Spare
17/3 Spare
18/1 Spare
18/2 Checksum high byte
18/3 Checksum low byte
11.14 Receive Real Time Clock ( 3 11 14 )
Msg byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
2/2 spare
2/3 Command + Subcommand = 0xbe
3/1 Hours byte (0-23)
3/2 Minutes byte (0-59)
3/3 Seconds byte (0-59)
4/1 Day byte (0-31), (0=Shutdown Clock)
4/2 Month byte (1-12)
4/3 Year byte (0-99)
5/1 spare
5/2 Checksum high byte
5/3 Checksum low byte
11.15 Receive Programmable Output Delays ( 3 11 15 )
Msg Byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
2/2 Spare
2/3 Command + Subcommand = 0xbf
3/1 OUT 5 delay high byte (0.00-60, *100)
3/2 OUT 5 delay low byte
3/3 OUT 7 delay high byte (0.00-60, *100)
4/1 OUT 7 delay low byte
4/2 OUT 4 delay high byte (0.00-60, *100)
4/3 OUT 4 delay low byte
5/1 OUT 6 delay high byte (0.00-60, *100)
5/2 OUT 6 delay low byte
