30 Electro-pneumatic positioner TZID 42/18-54 EN
This list applies to a full Autostroke. When using a PC with TZID software, you can also
execute a partial Autostroke, as listed below:
• Stops only (steps 10 to 32/200)
• Parameters only (steps 40 to 120/200)
• Zero only (refer to the list below for the steps and their meaning
1
)
Display Autostroking function
10 Move actuator to closed position.
11 Save closed position.
12 Determine and save resolution (A/D
conversion)
13 Zero adjustment
200 Autostroke completed
1. A “Zero“ Autostroke requires that the range has been determined before using the
TZID software.
