ABB TZIDC-110 - Attaching Mounting Bracket and Positioner

Mounting
42/18-84-EN TZIDC, TZIDC-110, TZIDC-120 23
2. Attach mounting bracket on the positioner
Fig. 13
1 Mounting bracket
3. Attach positioner to the actuator
Fig. 14
IMPORTANT (NOTE)
After mounting the unit check whether the operating range for the actuator matches the sensor
range on the positioner.
