14
Installation room
Room layout
IAC A-FL 12.5 kA, 1sec against a wall IAC A-F 16 kA
Figure 25. Distances from the walls of the installation room
with compartment for the exhaust gas on the rear,
solution IAC A-FL 12.5 kA, 1s against the wall
Figure 26. Distance from walls of installation room with gas
exhausting compartment at rear, solution IAC A-F 16 kA 1s
ATTENTION
IAC A-FL version – No access to Rear side of the
Swb while is in service. Installation distances to be
respected
ATTENTION
IAC A-FL version – Do not access the rear or side
parts of the switchgear while this is under service
conditions. Compliance with the installation
distances is mandatory
—
