Electromagnetic Flowmeter
WaterMaster 3 Mechanical Installation
IM/WM Issue 7 9
Fig. 3.14 Cable Routing
Fig. 3.15 Gasket Fitting
Fig. 3.16 Separation of Sensors
Fig. 3.17 Access to Transmitter
70 °C (158 °F) Max.
– 20 °C
(– 4 °F)
Min.
Fit Gaskets
Gaskets Same Size as Pipe
0.7 m (2.3 ft) Min.
Position to enable access
to display and
communication connector
