Electromagnetic Flowmeter
WaterMaster 4 Electrical Installation
IM/WM Issue 7 19
4.2 Remote Transmitter/Sensor Arrangement
Fig. 4.6 Pipelines with Cathodic Protection
Note. For bonding connections use ≥ 4mm
2
(< 10AWG) cable.
Fig. 4.7 Remote Transmitter in Roadside Cabinet
Fluid Contact Rings
Bonding Cables (Supplied)
Caution. Do NOT ground
cathodically protected
systems
Power Supply
To Next Page
