ABB WaterMaster - 4.3 Transmitter Terminal Connections

Electromagnetic Flowmeter
WaterMaster 4 Electrical Installation
18 IM/WM Issue 7
Fig. 4.3 Flanged Metal Pipe to Plastic Pipe
Fig. 4.4 Metal Pipe with Plastic Make-up Insert
Fig. 4.5 All Plastic Pipe
Plastic Pipe
Metal Pipe
Optional fluid
contact ring
Plastic Pipe
Metal Pipe
Optional fluid
contact ring
Refer to Section 4.2, page 19
Optional fluid contact rings
