The IPG has the following operating parameters.
Table 4. Operating parameters for the IPG
Parameter
Tonic Range
Tonic Steps
Burst Range*
Burst Steps*
Pulse width 20–1000 µs
10 µs
(20–500 µs range)
50 µs
(500–1000 µs
range)
50–1000 µs 50 µs
Frequency 2–200 Hz 2 Hz — —
200–500 Hz
10 Hz
—
—
500–1200 Hz 20 Hz — —
Burst rate
frequency
— — 10–60 Hz 10 Hz
Intraburst
frequency
— — 250–500 Hz 10 Hz
500–1000 Hz 20 Hz
Amplitude 0–25.5 mA 0.1–1.0 mA
0–12.75 mA 0.05–0.50 mA
0–12.75 mA 0.05–0.50 mA
NOTE: Columns with * represent operating parameters for BurstDR™ stimulation programs
on IPGs capable of BurstDR stimulation mode.
NOTE: For each tonic program, you have the option to select the amplitude range. For
information on setting the amplitude range, see the clinician's programming manual for this
system.
NOTE: The number of stim sets in use for a tonic program governs the maximum frequency
(1200/number of stim sets).
NOTE: The maximum current depends on the impedance, frequency, and pulse width
settings.
Compatibility Guidelines for IPGs with Compatible Headers
IPGs with compatible headers are compatible with the following Medtronic‡ leads and extensions
available before May 5, 2015.
Table 5. Compatible Medtronic leads and extensions
Device
Model
Permanent lead
3776-45, 3776-60, 3776-75, 3876-45, 3876-60, 3876-75, 3777-45, 3777-60,
3777-75, 3877-45, 3877-60, 3877-75, 3778-45, 3778-60, 3778-75, 3878-45,
3878-60, 3878-75, 39286-30, 39286-65, 39565-30, 39565-65
Extension
3708120, 3708140, 3708160, 3708220, 3708240, 3708260, 3708320,
3708340, 3708360, 3876, 3877, 3878
WARNING: The use of Medtronic leads or extensions other than those specified in this
table may increase risk to the patient, including the potential for tissue damage.
