Abbott Proclaim 3667 - Bluetooth Smart Wireless Technology Information; Radio Transmitter, Cables, Transducers

27
Table 14. Registration identification information
Identifier Type
Registration Identifier
FCC registration number RIASJMRFC
Industry Canada (IC) registration number IC: 8454A-M3660123
Wireless Technology Information
The following table summarizes the technical details of the Bluetooth
®
Smart wireless technology
as it is implemented in the device.
Table 15. Bluetooth Smart wireless technology information
Antenna type
Embedded patch antenna in header
Antenna dimensions
8.1 mm x 5.1 mm x 4.9 mm
Modulation
GFSK
Magnetic field strength (at 2 m distance)
16.3 µA/m
Electric field strength (at 2 m distance)
6.1 mV/m
Output power (EIRP*)
1 mW (0 dBm) typical, 10 mW (+10 dBm)
maximum
Range
1–2 m typical
Center frequency
2.44 GHz
Channel
40 logical channels
Bandwidth
2 MHz per channel
Data flow
Bi-directional
Protocol
Bluetooth Smart wireless technology
*EIRP = Equivalent isotropically radiated power
Radio Transmitter, Cables, Transducers
The device contains a radio transmitter/receiver with the following parameters.
Radio transmitter parameters:
 Frequency (range): 2.4000 to 2.4835 GHz
 Bandwidth (-15dB): 2.398 to 2.4855 GHz
 Channel: 40 logical channels using AFH
 Modulation: GFSK
 Radiated output power: 10 mW (+10 dBm) maximum
 Magnetic field strength (at 2 m distance): 16.3 µA/m
 Duty cycle: Variable, but low (<5%)
 Semi-duplex capability
