Abbott Proclaim 3667 - Energy Factors for Tonic Stimulation Parameters

19
Energy Factors for Tonic Stimulation Parameters
The following tables show energy factors according to various stimulation parameters for tonic
programs.
NOTE: Energy factors are for IPGs that provide 12 hours of daily stimulation. For an IPG that
is providing 24 hours of daily stimulation, double the energy factor shown in the table.
Table 6. Energy factors for various tonic stimulation parameters (350-ohm impedance)
Pulse Width (µs)
Amplitude (mA)
Frequency (Hz)
100
200
300
500
30
13 14 14 15
1 60
18 19 20 23
90
22 24 26 29
30
15 17 20 24
2 60
21 26 30 40
90
27 34 41 54
30
16 19 23 30
3 60
24 30 37 51
90
30 41 51 71
30
17 22 26 47
4 60
26 35 44 85
90
34 47 61 122
30
21 30 38 55
5 60
34 51 68 102
90
46 71 97 148
30
23 33 43 81
6 60
37 58 78 152
90
51 81 112 223
30
29 44 60 92
7 60
49 80 112 175
90
68 115 162 257
30
31 49 67 125
8 60
53 89 125 242
90
74 129 183 359
30
33 64 89 139
9 60
58 118 169 271
90
81 173 249 401
30
41 69 97 182
10 60
73 130 186 355
90
105 190 274 528
