Quick Installation
A-3
Watch the pin position and the
orientation
J6 - There is a specific orientation for pin 16 to pin 20. Insert the five-threads
keylock cable into correct pins of connector on the mainboard.
Pin number Name of the signal or signification
20 +5VDC
19 No connection
18 Ground
17 Keyboard inhibit Signal
16 Ground
Watch the pin position and the
orientation
J5 - There is a specific orientation for pin 1 and pin 4. Connect the two-threads
IDE LED connector to the connector on mainboard.
Pin number Name of the signal or signification
1 Activity LED Cathode
2 IDE LED signal ¡i LED Anode ¡j
3 IDE LED signal ¡i LED Anode ¡j
4 Activity LED Cathode
Watch the pin position and
the orientation
J6 - There is a specific orientation for pins 6 and 7. Connect the two-threads
suspend switch connector of the computer case to correct pins of connector on
the mainboard. You can ignore this connector since most of computer cases do
not support this feature (the mainboard itself supports it).
Pin number Name of the signal or signification
7 Suspend
6 Ground
Installing Keylock connector:
Installing IDE LED connector:
Installing Suspend switch connector:
