BIOS Setup
AX78 2-3
- NB/SB A-LINK Clock
This item selects the clock frequency for A-LINK between NB and SB.
- PCIe x16 Clock
This item selects the clock frequency for PCI Express slot [PCIEXP1].
- PCIe Clock
This item selects the clock frequency for PCI Express slot [PCIE1].
Voltages Control
This option allows you to switch between the default and user-defined voltages. Leave this
setting at default unless the current voltage setting cannot be detected or is not correct. The
option “User Define” enables you to select the following voltages manually.
- CPU Core Voltage
- CPU Core NB Voltage
(This item appears only with AM2+ CPU)
- DDR2 Voltage
- DDR2 Reference Voltage
- NB 1.8V Voltage
- NB 1.1V Voltage
- SB 1.2V Voltage
- Hyper Transport Voltage
- V1P2 Dual Voltage
2.2 Standard CMOS Features
Phoenix – AwardBIOS CMOS Setup Utility
Standard CMOS Features
Date (mm:dd:yy) Wed, Nov 28 2007 Item Help
Time (hh:mm:ss) 12 : 34 : 56
► IDE Channel 1 Master None
► IDE Channel 1 Slave None
► SATA Channel 1 None
► SATA Channel 3 None
► SATA Channel 2 None
► SATA Channel 4 None
Drive A 1.44M, 3.5 in.
Floppy 3 Mode Support Disabled
Halt On All, But Keyboard
Base Memory 640K
Extended Memory 1047552K
Total Memory 1048576K

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Date (mm:dd:yy)
This item sets the date you specify (usually the current date) in the format of [Month], [Date],
and [Year].
