Hardware Setup 2-15
(12). Accelerated Graphics Port Slot [AGP1]
This motherboard provides an “AGP Pro 50” slot with up to AGP8X support.
To install an “AGP Pro 50” compliant card, the small plastic retention piece located in the AGP1 slot
must be removed first (simply by your fingertips, and keep it for future use).
NOTE: Remove this plastic retention piece only when installing the “AGP Pro 50” compliant card. To
install a regular VGA card will require this retention piece back in its original position to keep the VGA
card from sliding back and forth, or even damage the VGA card and/or motherboard.
ATTENTION: This motherboard does not support 3.3V AGP cards. Use only 1.5V or 0.8V AGP cards.
