2-16 Chapter 2
(13). Serial ATA Connectors
These connectors are provided to attach one Serial ATA device at each channel via Serial ATA cable. A
RAID 0 or RAID 1 array is also available by software configuration.
To enable the SATA1 and SATA2 controller, the item “OnChip SATA Device” must be kept enabled
(default setting) in the BIOS menu of “OnChip IDE Device”.
KV7 Series
