Abloy DB001 - DA033 Elbow Switch and DA039 and DA049 Rotary Switch

29
Program selector connection according page 25..
CONNECTION EXAMPLES
DA033 Elbow switch
DA039 and DA049 rotary switch
COM N.O N.C
5678
TB2
91011121314
FS
ON
12345678
Red
Black
Yellow
5678
TB2
91011121314
1
2
3
NOTE!
FS1 = OFF
Add diode for example 1N4004
Diode is not included in the delivery.
Kill - Kill + 0VDC Key impulse Lock control +24VDC for lock 0VDC 24 VDC MVI impulse Outer impulse
