Abloy DB001 - Connection Examples Control Unit and Extension Unit EXB-FI; Electric Locks EL402, EL404, EL502

33
Electric locks EL402, EL404, EL502
Blue
Black
Green
Red
0 VDC
24 VDC
Presence impulse
Not in use Presence detection Not in use
Not in use
100µF
50V
CONNECTION EXAMPLES CONTROL UNIT AND EXTENSION UNIT EXB-FI
Electric locks EL402, EL404, EL502
CONTROL UNIT
EXTENSION UNIT EXB-FI
26
27
28
32
31
30
29
TB4
FS
ON
12345678
NOTE!
FS4 = ON
FS5 = ON
5678
TB2
91011121314
Kill - Kill + 0VDC Key impulse Lock control +24VDC for lock 0VDC 24 VDC MVI impulse Outer impulse
NOTE! Capacitor 100µF / 50V is not included in the delivery.
