Abloy DB001 - Page 37

37
Active door Passive door
FS
ON
123456
7
8
Adjust opening delay and
Key hold open time to 0
second.
All impulse devices must be connected to active door control unit.
With this connection it is possible to feed more current to impulse devices.
5678
TB2
91011121314
TB1
1
3
2
Motor Control
0 VDC
Slave control
+24 VDC
CONNECTION OF DOUBLE DOORS
5
6
7
8
9
1
0
1
1
1
3
12
14
5
6
7
8
9
1
0
11
13
12
14
TB1
TB2
NOTE!
FS1 = ON
FS7 = ON
Kill - Kill + 0VDC Key impulse Lock control +24VDC for lock 0VDC 24 VDC MVI impulse Outer impulse
