- 07 -
Front installation
No maintenance access：Cabinet from the front to install, no need maintenance access, the cabinet thickness
(including steel structure) is only 150 mm, about 1/8 of the traditional display thickness, save installation space；
Installation steps
• Remove the corner four modules；
• Fix the cabinet to the steel structure;
• Connect the cables;
• Recovery the modules.
Front maintenance
Leading LED Applications
Rear install hole Front install hole
The tool is fixed on the module Pull the tools out
Take the module down Do the maintenance
Product features
K series
User Manual
