KL II Series User Manual 26
The loading pixel dots of each network port cannot exceed 650,000 pixels. Before wiring, it is must be
connected according to the network cable load scheme designed before sales. The KL II series network
cables are loaded as below:
5.3 Power cord and signal test
After completing the cabinet wiring, please use a multimeter to measure whether there is a short circuit
at the AC input terminal (L/N/PE) and DC output terminal (VCC/GND) of the power supply. If you find a
short circuit, please check the wiring carefully. After ensuring that the line is normal, power on the
cabinet to work.
After confirming that the screen is energized normally, connect the computer and the sending box, and
use the NovaLCT software to configure the LED display screen configuration settings.
Note: For software operations, please refer to the Nova LCT software
operating instructions.
Loading capacity for
each sending card
port
When calculating the
actual maximum
number of cabinets
loaded by a sending
card network port ,
calculate the number
of cabinets in the
rectangular area
loaded by the
network cable
To Next Page
