Sub-frame

Front installation hole

Sub-frame

Wall-mounting Solution

Front Installation Instructions (Wall-mounting)

Install cabinets onto the sub-frame or fixed structure, and then directly mount the sub-frame onto the wall,

to achieve wall-mounting installation.

Step 1:

Install cabinets onto the sub-frame and splice 2 to 4 cabinets. Number of cabinets is based on actual

requirements at installation site.

Wall Wall mounting device

Absen N5 User Manual
