NX Series Product User Manual
4.4 The test of setting up an electric circuit
After the cabinet connection is completed, please use a multimeter to measure
whether there is short circuit at the AC input (L/N/PE) and DC output
(VCC/GND) of the power supply. If a short circuit is found, please check the
circuit carefully. After ensuring the cable is normal, switch on the power to
electrify the cabinets to work.
Note: Please refer to the software user manual for software operation.
Cabinet-connected
network cable
