10
HDCC82500
Einstellung der Dome ID (SW1, alle DIP):
Dome ID
(Adresse)
1 2 3 4 5 6 7 8
0 OFF OFF OFF OFF OFF OFF OFF OFF
1 ON OFF OFF OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF OFF OFF
3 ON ON OFF OFF OFF OFF OFF OFF
- - - - - - - - -
255 ON ON ON ON ON ON ON ON
Einstellung der Kommunikationsparameter (SW2, DIP 1 und 2):
DIP Switch SW2 – Baudraten Einstellung
Baudrate 1 2 3
2400 OFF OFF OFF
9600 ON ON OFF
4800 OFF ON OFF
