Abus TVAC14000A - Page 43

43
English
You can also swivel the mount by 90° into a particular position. First loosen the screw on the side and
set the required angle. Then tighten the screw to secure the required position.
Then screw the camera onto the mount and connect the power supply unit with the camera.
Mounting options:
Ceiling
mounting
Wall installation
