5.3 Camera description
Meaning of the LEDs:
LED
Status
Meaning
Power LED 
On (red)
Camera on
Off
Camera off
Link LED 
Flashing
The camera is in the “Pairing Mode”.
On (green)
Camera is connected to the monitor
Off
Camera is in standby

Antenna

Fixed lens

Power LED

Link LED

IR LED

Photo sensor

Camera mount

Microphone

Pairing button

Power supply connection
5 VDC / 1A












