24
Article number TVCC10041 TVCC10541
Standard
PAL
Resolution
520 TVL
Image Sensor
1/3“ WD CCD
Picture elements (total)
795 Pixel (H) x 596 Pixel (V)
Picture elements (effective)
752 Pixel (H) x 582 Pixel (V)
Signal-to-noise ratio
48 dB
Minimum light sensitivity (day)
0.2 Lux @ F2.0, 50 IRE 0.8 Lux @ F2.3, 50 IRE
Lens
6 mm, Fix lens 3.6 mm, Fix lens
Lens type
Mini Pinhole
Synchronization
Internal
Automatic Gain Control (AGC)
Automatic
Shutter
AES
Backlight compensation (BLC)
Automatic
White balance
Automatic White Balance (AWB)
Gamma
0.45
WDR range
46 dB
Video signal
Composite; 1.0V p-p, 75 Ohm
Operating temperature
-10°C ~ +50°C
Humidity
0~85%, not condensing
Nominal supply voltage
12 VDC
Power consumption
0.8 W
Dimensions (WxHxD)
32 x 32 x 42 mm 32 x 32 x 25 mm
Weight
45 g 35 g
