4.3 Installing the TVCC81500 on a wall
1. Install the desired mount, see point 7 “Installing the mounts”.
2. Remove the adhesive strips from the dome.
3. Attach the mounting plate to the mount.
4. Configure the dome address, baud rate and other settings using the SW 1 and SW 2 DIP switches,
see description, point 3).
As the speed dome adapts automatically to PELCO-D and PELCO-P, no setting with regard to
the protocol is required here.
