Abus TVIP41560 - 12 Technical Data

English
12. Technical data
Model number
TVIP41560
TVIP61560
Dimensions (L x W x H) Ø111 x 82 mm 145 x 61 x 60 mm
Danger detection
Email
Connections
1xRJ45, 1xDC
Number of parallel
streams
2
Resolution modes
Main Stream: 1280 x 960, 1280 x 720, 704 x 576, 640 x 480
Sub Stream: 704 x 576, 640 x 480, 352 x 288, 320 x 240
Motion detection
Yes
Image sensor
1/3" progressive scan CMOS sensor
Pixels (effective)
1280 x 960 pixels
Image overlay
Date, camera name, private zones
Frame rate
25 fps
Focal length
4.0 mm @ F2.0
Dynamic range (WDR)
Digital WDR
Electronic shutter
regulation
1/3 – 1/100000 Sec.
Backlight compensation
BLC, DWDR
Simultaneous network
access
Yes
Horizontal angle of view
73.1°
73.1°
IR range
10 m
Camera type
Day/Night Outdoor Camera
Day/Night Outdoor Dome Camera
Max. resolution @ frame
rate
1280 x 960 @ 25 fps
Max. operating
temperature
50°C
Max. humidity
95%
Min. operating
temperature
-20°C
Minimum illumination
colour
0.1 Lux @(F1.2, AGC an)
Minimum illumination
B/W
0 Lux
Video network
bandwidth
32 kBit/s – 8 MBit/s
LAN network access
RJ-45 Ethernet 10/100 Base-T
WLAN network access
IEEE802.11b, 802.11g, 802.11n
Network camera
protocols
TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP,
UPnP, SMTP, 802.1X, IPv6, Bonjour
ONVIF
Profile S
Private zones
Yes (4)
Noise reduction
3D DNR
IP protection class
66
Power supply
12 V DC (+/-10%), PoE (802.3af)
Storage medium
microSD card (up to 64 GB)
Language of instructions
DE, UK, FR, NL, DK, ES, IT, PL, SWE
OSD language
DE, UK, FR, NL, DK, ES, IT, PL, SWE
Current consumption
Max. 580 mA
Day/night switching
Electromechanically removable IR cut filter (ICR)
Supported browsers
Mozilla Firefox, Safari or Internet Explorer 6.x and higher
Supported software
ABUS VMS Express, IPCam App (iOS/Android)
Encryption
64/128 bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Video compression
H.264, MJPEG
White balance
AWB
Certifications
CE, RoHS, REACH
137
