18
PROGRAMMING
HEATING TRIGGER
If the heater is turned off,
the probe will detect a lower
temperature than your Heating
Trigger, telling the fans to turn off.
Your central heating
system turns on.
Heated air blows through the
duct and into your room.
1 2
Temperature you set in
Heating Trigger
Fans Not Running Fans Running
0°F 120°F
Probe Temp F/C°
The fans will pull heated air
from your duct to boost your
heater output.
When the probe detects the airflow
temperature has risen above your Heating
Trigger, it will activate the fans.
3
4
