INSTALLATION
STEP 1
Determine your desired mounting location free
of obstruction (studs, waterlines, electrical
cords, etc.). Make sure this mounting location
is 3.5 to 6 inches thick.
Mark the center point, mounting points, and
cylinder outline using the rear faceplate stencil.
STEP 2
From the center point, measure the length to
the end of your wall (X) and the height to the
floor (Y).
Keep these measurements for step 7.
X
Y
