5.4 Indicator control
These commands control the behaviour of the ‘Good Read’ and ‘Bad Read’ LEDs.
Table 5. Indicator LED commands
Command
Description
Default
Parameters/Range
AISGDT
‘Good Read’ LED indicator duration.
Each unit is equivalent to 100
milliseconds.
5
0–200
AISGDS
‘Good Read’ duration start.
Specifies when the ‘Good Read’
indicator illuminates.
0
0 - At ‘Good Read’
1 - At media removal
AISGIN
‘Good Read’ indication stop.
Specifies when the ‘Good Read’
indicator extinguishes.
1
0 - At media removal
1 - Continues after media
removal
AISBDT
‘Bad Read’ LED indicator duration.
Each unit is equivalent to 100
milliseconds.
8
0–200
AISBDS
‘Bad Read’ duration start.
Specifies when the ‘Bad Read’ indicator
illuminates.
0
0 - At ‘Bad Read’
1 - At media removal
AISBIN
‘Bad Read’ indication stop.
Specifies when the ‘Bad Read’ indicator
extinguishes.
1
0 - At media removal
1 - Continues after media
removal
AISGSL
Switches between LED locations for the
‘Good Read’ indicator.
5
0 - No lights
1 - Board green lights
2 - Board red lights
4 - Lid green lights
5 - Lid and board green
lights
8 - Lid red lights
10 - Lid and board red
lights
AISBSL
Switches between LED locations for the
‘Bad Read’ indicator.
10
0 - No lights
1 - Board green lights
2 - Board red lights
4 - Lid green lights
5 - Lid and board green
lights
8 - Lid red lights
10 - Lid and board red
lights
