Access IS LSR118 - 2. Specifications; LSR118 Product Specifications

Page 7 of 77 Copyright © Access-IS 2020
2. Specifications
Specification
Details
Dimensions (L x H x W)
109.8 mm x 67.4 mm x 105.9 mm
Weight
592 g (with cable)
Environmental
Operating temperature: -25ºC to 50ºC
Storage temperature: -30ºC to 70ºC
Humidity: 95% RH, non-condensing
IP67
Body
Black ABS
Glass
4 mm Toughened White Soda Lime; BS EN60068-2-75 & IEC
62262:2002, rated to 3.5 J impact
Power requirements
5 V DC
Requires USB power injector cable or independent power supply
Electrical interface
Serial (RS232C) and 5 V USB
Barcode reading
Reads barcodes from mobile phones, tablets and paper
Linear: Code 2 of 5, Interleaved 2 of 5, EAN13, Code 3 of 9,
Code 128 (plus others)
2D: PDF417, QR, Aztec, DataMatrix, (plus others)
NFC
EMV: Certified to Level 1
Supported media: ISO14443 type A and B cards (Java cards);
max baud 424K (extendable to 848K)
MIFARE UL, Classic 1K, Classic 4K, UL-C, MIFARE Plus; max
baud 106K
MTBF
85,000 hours
Approvals
CE EMC Class B
• EN 55022
• EN 55024
CE Low Voltage Directive
• EN 60950-1
• IEC 62471: 2006 - Exempt Class
CE R&TTE Directive
• ETSI EN 301 489
• ETSI EN 302 291
FCC 47CFR Part 15 Subpart B Class A
FCC 47CFR Part 15 Subpart C
IEC 60825-1 LED Safety Class 1
