3. Installation
3.1 Unpack the LSR118
Unpack the LSR118 and ensure that you have the following items:
• Advisory notice card.
• LSR118 device with attached serial cables or USB cable.
• USB power injector cable or power supply (IEC cable not supplied).
Report any missing items or damage immediately to your Sales Representative.
3.2 Connection
Connect the LSR118 directly to two RS232 ports or a USB port depending on the product version.
Note: The cable is sealed into the unit to prevent entry of water, moisture and dust. Cable length is
2 m for serial and USB versions.
3.2.1 Connection to RS232
Figure 2. Connection to RS232
3.2.2 Connection to a USB port
Figure 3. Connection to USB
Serial and power cables connected to LSR118 device
USB power injector cable to a powered USB port
on host PC (or connection to an external power
supply)
To COM ports on the host PC
To a USB port on the host PC
USB and power cables connected to LSR118 device
USB power injector cable to a powered USB port
on host PC (or connection to an external power
supply)
