Accu-Chek Inform II Manual

0 8403414001 (01) 2017-11 EN-USA • Accu-Chek Inform II Addendum to Operator’s Manual 9
Technical data
* Accu-Chek Inform II Base Unit Light
** Accu-Chek Inform II Base Unit Hub
Specification Accu-Chek Inform II
Base Unit Light (NEW)
Power supply unit (NEW)
Height 123 mm / 4.84 in (max.) 35 mm / 1.38 in +
AC plug (28-40 mm /
1.1-1.6 in)
Width 130 mm / 5.12 in (max.) 51 mm / 2.01 in
Length 130 mm / 5.12 in (max.) 87 mm / 3.43 in
Weight Accu-Chek Inform II
Base Unit Light
approx. 660 g with wall mount
170 g
User interface LED (bicolor: red, green) N/A
Operating temperature 3 to 50 °C
37 to 122 °F
0 to 40 °C
32 to 104 °F
Storage conditions (long-term storage) 5 to 40 °C / 41 to 104 °F at 10 - 85% RH (non-condensing)
Humidity (operating) 10 - 90 % RH (non-condensing)
Input voltage +12V DC 100 to 240 V AC
Input frequency DC 50 to 60 Hz
Input current 1.25 A (max) 350 to 150 mA
Interfaces Charging contacts
IR port
RJ25 for connecting to Hub
DC connector
Replaceable AC input contacts
Data transfer rate When used in combination
with the Base Unit Hub:
IR: 9.6K - 115K bps*
Ethernet:
10 Mbps half-duplex**
N/A

Accu-Chek Inform II Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Memory Capacity	1000 test results
Display	LCD
Measurement Range	10 to 600 mg/dL
Connectivity	Infrared
Sample Type	Capillary whole blood
Operating Temperature	16 to 32°C (61 to 90°F)
Relative Humidity	10 to 90% non-condensing
