10
4. Position the new code chip so the code number
faces away from you. Push the code chip into
the code chip slot until the code chip snaps into
place.
NOTE
• If you see code and a flashing - - - on the display, insert a code chip into the meter.
• Do not force the code chip into the meter. There is only one correct way to insert the code chip.
• Leave the code chip in the meter until you open a new test strip box. Once you receive a black code
chip, you do not need to change the code chip again.
50705_05853397002_EN.indb 10 4/24/12 8:32 AM

Accu-Chek Performa Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Meter Dimensions	94 x 52 x 21 mm
Measurement Range	0.6-33.3 mmol/L
Memory Capacity	500 results
Battery Type	1 x CR2032 lithium coin cell
Automatic Power Off	90 seconds after last user action
Operating Humidity	10 to 90% RH
Storage Conditions	10% to 90% RH
Meter Weight	59 g (with battery)
