Accuniq BC360 - Assembling a Bluetooth (Option)

77
3. Assembling a Bluetooth (option)
Connect the provided Bluetooth to the BLUETOOTH port on the back side of the device.
Users can check and manage the result data on the exclusive mobile device app via Bluetooth
connection.
Components for Bluetooth①
Unscrew the (+) bolts (2EA) and cable grand (1EA) with a (+) driver. Keep the separate (+) ②
bolts (2EA) and cable grand (1EA) to assemble a bracket and cable later.
Antenna
Bluetooth
Bracket
Cable
(+)Bolt
2EA
Cable
grand
Union of bracket
