81
② Detach the top cover from the scale by using a (-) driver.
③ Check the RS-232C port of the weight scale and ankle electrode.
④ Connect the RS-232C port of the ankle electrode to the weight scale as shown in the picture.
Ankle electrode
RS-232C port
Ankle electrode
RS-232C port
