Thermal Switch Assembly (716-0612-00)
Ass'y
Receiver Assembly (721-0064-00)
Ass'y
Connector Plug 308-0209-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ
Thermal Switch 369-0019-00 TS1
ｻｰﾏﾙｽｲｯﾁ
－８－
Mete
Connecto
ssembly (716-0602-00)
Ass'y
Fuse Holder 306-2001-00 FH1,2
ｺﾈｸﾀﾌﾟﾗｸﾞ
Power Push Switch 354-1024-00 S1
ﾊﾟﾜｰﾌﾟｯｼｭｽｲｯﾁ
Power Switch Assembly (716-0603-00)
Ass'y
S1
TS1
K1
K1
FH2
Connector Plug 308-0412-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ
FH1
R1
IC1
PL2
PL1
PL3
K1
Infrared Ray Senser NJL62H380A IC1
赤外線ﾚｼｰﾊﾞ
Electorlytic Capacitor CE04W0J470MA 47uF /6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
Carbon Film Resistor R2 RD142EA470J 47
Ω
1/4W
炭素皮膜抵抗器
Oxide Metal Film R1 RS143FA680JS-P 130
Ω
3W
Resistor
金属酸化物被膜抵抗器
Pilot Lamp 176-7501-00 PL1,PL2,PL3
ﾊﾟｲﾛｯﾄﾗﾝﾌﾟ
Connector Plug 308-0530-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ
Input Selector Assembly (716-0614-00)
Ass'y
Connector Plug 308-0708-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ
LED TLS-262-C D2,3,4,5,6
D6
K1
D5
D4
D3
D2
