1.[SCAN S/N AND M/B CODE]
2.[FASTEN BKT AND BEZEL IN THE LEFT
SIDE WITH SCREW 3*PCS ]
3.[TURN LCD]
1.[FETCH BUTTON/B AND INSERT IT INTO
BEZEL]
2.[STICK 1*PCS RUBBER AT THE
APPOINTED PLACE]
1.[GET SHIELD ON THE BKT R/L]
2.[INSERT LCD CABLE INTO PANEL
CONNECTOR]
3.[STICK 1*PCS YELLOW TAPE TO
FASTEN LCD CABLE]
4.[TRIM WIRES AND ASSEMBLE SHIELDING
IN RIGHT POSITION]
1.[LOCK 4*PCS SCREW(M3*4-T) TO FASTEN
PCB SHIELD]
