Acer AN515-51 User Manual

Service and Maintenance 5-125
WLAN Antenna (Aux) Removal
Prerequisite:
LCD Panel Brackets Removal on page 5-114
1. Starting from the bottom left side, carefully unroute the eDP cable and detach the mylar.
2. Continue to unroute the eDP cable from the guides on the left and top sides of the LCD cover.
While unrouting the cable, make sure to detach the mylar (closer to the CMOS and microphone
module).
Figure 5-187. Unrouting the eDP Cable

Acer AN515-51 Specifications

General

Processor	Intel Core i5-7300HQ
Graphics	NVIDIA GeForce GTX 1050
RAM	8GB DDR4
Operating System	Windows 10 Home
Display	15.6 inch, 1920 x 1080 pixels
Battery	48Wh
Weight	2.7 kg
