Service and Maintenance 5-58
3. Attach the six (6) M2.0 x 2.5 screws (marked as A) and the eleven (11) M1.7 x 2.5 screws to
secure the keyboard plate and the keyboard to the upper case.
Figure 5:79. Securing the Keyboard Plastic
4. Install the upper case (see Upper Case Installation on page 5-36).
Table 5:17. Keyboard Screws
Screw Name Screw Type Quantity
M 1.7 x 2.5 11
M 2.0 x 2.5 6
