162 Chapter 5
Bottom View
JP7 Touch Pad Connector JMDCI USB Connector
JP3 FP/B Connector JP8 Keyboard Connector
JP9 Fun/B Connector JP2 USB/B Connector
Item Description Item Description
PJP3 AC-IN Connector JRJ45 RJ45 Connector
JCRT1 CRT Connector PJ13 TBD
JUSB2 USB Connector JHDMI1 HDMI Connector
Item Description Item Description
VGA UMA
Discrete VGA
To Next Page
