Acer Aspire 4540 Series - Removing the LCD Module

62 Chapter 3
Removing the LCD Module
1. See “Removing the Speaker Module” on page 60.
2. Remove the adhesive tapes securing the Antenna cables to the Upper Cover.
3. Turn the computer over. Remove the two securing screws as shown.
4. Lift the securing tape to expose the Antenna cable as shown.
Step Size Quantity Screw Type
LCD Module M2.5*5 2
