Machine Maintenance 3-37
Removing the LCD Module 0
1. Perform the “Removing the Mainboard” procedure described on page 3-28.
2. Gently pull out the WLAN antenna cables from lower case; remove the adhesive tapes
securing the cables and release the cables from the latches.
Figure 3-46. WLAN Antenna Cables - Latches and Adhesive Tapes
3. Remove the two screws securing the LCD module.
Figure 3-47. LCD Module Hinge Screws
Table 3-47. Screws
Step Screw Quantity Screw Type
LCD Module Disassembly M2 ×3 1
M2.5 ×L5 1
To Next Page
