3-70 Machine Maintenance
Reinstalling the Palmrest Module/Upper Case 0
1. Place the upper case into the lower case assembly.
Figure 3-101. Upper Case
2. Secure the upper case to the lower case assembly using three screws.
Figure 3-102. Upper Case Screws – Top Side
Table 3-102. Screws
Step Screw Quantity Screw Type
Upper Case Reassembly M2.5 × L5 3
To Next Page
